226823A1 REVERSIBLE PTO SHAFT. Genuine McCormick reversible PTO shaft for McCormick tractors and Case tractors.

Specification:

• 1³/₈” inch spline diameter
• 6 spline 540 rpm
• 21 spline 1000 rpm
• Shaft length 228mm

Fitted to tractors:

• Case IH 51 Series (1990 – 1997)
  5120, 5130, 5140, 5150
• Case IH MX Series (1998 – 2002)
  MX80C, MX90C, MX100C, MX100, MX110, MX120, MX135, MX150, MX170
• McCormick MC Series Tier 1/2/3 (2002 – 2010)
  MC80, MC90, MC95, MC100, MC105, MC110, MC115, MC130, MC120 POWER 6, MC135 POWER 6
• McCormick MTX Series Tier 1/2/3 (2002 – 2007)
  MTX110, MTX120, MTX125, MTX135, MTX140, MTX145, MTX150, MTX155, MTX165, MTX175, MTX185, MTX200
• McCormick XTX Series Tier 2/3 (2005 – 2013)
  XTX145, XTX165, XTX185, XTX200, XTX215
• McCormick TTX Series Tier 3  (2007 – 2013)
  TTX190, TTX210, TTX230
• McCormick X70 Series  (2012 – 2013)
  X70.40, X70.50, X70.60, X70.70, X70.80
